Round flow cassette

Round Flow - FCAG-B

360° air discharge for optimum efficiency and comfort

Product Features

Combining with R-32 Bluevolution technology, reduces environmental impact with 68% compared to R-410A, leads directly to lower energy consumption thanks to its high energy efficiency and has up to lower 16% refrigerant charge
Optional automatic filter cleaning panel results in higher efficiency & comfort and lower maintenance costs.
Two optional intelligent sensors improve energy efficiency and comfort
Lowest installation height in the market: 214mm for class 20-63
Widest choice ever in decoration panels: designer panels in white (RAL9010) and black (RAL9005) and standard panels in white (RAL9010) with grey louvers or full white
Unified indoor unit can be combined with R-32 and R-410A outdoor units, symplifying stock
Individual flap control: flexibility to suit every room layout without changing the location of the unit!
Bigger flaps and unique swing pattern improve equal air distribution
5 different fan speeds available for maximum comfort
Optional fresh air intake
Branch duct discharge allows to optimize air distribution in irregular shaped rooms or to supply air to small adjacent rooms
Standard drain pump with 675mm lift increases flexibility and installation speed

Benefits

Presence & floor sensor

The presence sensor directs the air away from any person detected in the room, when the air flow control is on. The floor sensor detects the average floor temperature and ensures an even temperature distribution between ceiling and floor.
Home leave operation

Maintains the indoor temperature at your specified comfort level during absence, thus saving energy
Auto-cleaning filter (optional)

The filter automatically cleans itself once per day. Simplicity of upkeep means optimum energy efficiency and maximum comfort without the need for expensive or time-consuming maintenance.
Draught prevention

When starting to warm up or when the thermostat is off, the air discharge direction is set horizontally and the fan to low speed, to prevent draught. After warming up, air discharge and fan speed are set as desired.
Individual flap control

Individual flap control via the wired remote controller enables you to easily fix the position of each flap individually, to suit any new room configuration. Optional closure kits are available as well.
Onecta app (optional)

Control your indoor climate from any location via smartphone or tablet
Fan only

The unit can be used as fan, blowing air without heating or cooling.
Auto cooling-heating changeover

Automatically selects heating or cooling mode to achieve the set temperature.
Whisper quiet

Daikin indoor units are whisper quiet. Also the outdoor units are guaranteed not to disturb the quiet of the neighbourhood.
Ceiling soiling prevention

Prevents air from blowing out too long in horizontal position, to prevent ceiling stains.
Vertical auto swing

Possibility to select automatic vertical moving of the air discharge flaps for efficient air and temperature distribution throughout the room.
Fan speed steps (5 steps + auto)

Allows to select up to the given number of fan speed.
Dry programme

Allows humidity levels to be reduced without variations in room temperature.
UV Streamer kit (optional)

Purifies the air of pollutants such as viruses, bacteria, fine dust, oudeurs, allergens, etc ensuring a healthy and hygienic indoor environment.
Air filter

Removes airborne dust particles to ensure a steady supply of clean air.
Weekly timer (optional)

Can be set to start heating or cooling anytime on a daily or weekly basis.
Infrared remote control (optional)

Starts, stops and regulates the air conditioner from a distance.
Wired remote control (optional)

Starts, stops and regulates the air conditioner.
Centralised control (optional)

Starts, stops and regulates several air conditioners from one central point.
Auto-restart

The unit restarts automatically at the original settings after power failure.
Self diagnosis

Simplifies maintenance by indicating system faults or operating anomalies.
Drain pump kit (standard)

Facilitates condensation draining from the indoor unit.
Infrastructure cooling

Remove in a reliable, efficient and flexible way the heat constantly generated by the IT and server equipment to ensure maximum uptime while offering the best return on investment.
Twin/triple/double twin application

2,3 or 4 indoor units can be connected to only a single outdoor unit even if they have different capacities. All indoor units operate within the same heating or cooling mode from one remote control.
Multi model application

Up to 5 indoor units can be connected to a single outdoor unit, even if they have different capacities. All indoor units can individually be operated within the same heating or cooling mode.
VRV for residential application

Up to 9 indoor units (even different capacities and up to 71 class) can be connected to a single outdoor unit. All indoor units can individually be operated within the same mode.
